Overview
Sunlike manufactures rotary feeders for controlled discharge and feeding of powders and granular materials. These units are commonly installed beneath silos, hoppers, and dust collection systems to regulate material flow.
Sunlike offers customized manufacturing based on project specifications and application requirements.
The Rotary Feeder is widely used for material discharge from dust collection equipment and for controlled feeding in bulk material handling systems. It is suitable for handling both powdered and granular materials.
Rotary Feeders are widely used in industries such as environmental protection, metallurgy, chemical processing, grain processing, and food production.
Features
- Compact structure — Compact design with a small footprint and easy operation.
- Smooth and quiet operation — Designed for stable operation with low noise.
- Suitable for high-temperature applications — The bearings and gearbox are positioned at a distance from the housing, helping reduce heat transfer and improve lubrication conditions.
Working Principle
The Rotary Feeder is designed for continuous and controlled feeding of powdered materials. The feeding rate can be adjusted by changing the rotational speed of the variable-speed motor. The transmission system consists primarily of a worm gear and worm shaft mechanism, providing stable and reliable speed transmission.
During operation, the material enters the upper section of the feeder from the hopper and flows into the pockets of the feeding rotor. As the rotor rotates, the material is carried through approximately 180° and discharged into the measuring rotor. The measuring rotor then rotates another 180°, transferring the material to the lower discharge outlet and subsequently into the discharge pipe.
This operating process enables continuous and uniform material feeding while helping prevent uncontrolled material flow when the feeder is stopped.
Applications
The Rotary Feeder can be used for handling a variety of powders and granular materials, including:
- Pulverized coal
- Cement and mineral powders
- Dust collected by dust collection systems
- Chemical powders
- Grain and other granular materials
